3.5T 大轮胎叉车 越野叉车

2爬坡角度：≤38°

3货叉长度：1220mm

4额定举升高度：3000mm（可定做3000-7000mm）

5额定举升重量：3500KG

6门架前端离地间隙：250-350mm

7转弯半径：3000mm

8驱动方式：四轮驱动

9轴距中心离地间隙：300mm

10发动机品牌型号：全柴493国四发动机36.8KW，国内知名品牌动力强劲，质量可靠，售后及时。

11变速箱：280双高低速变速箱，大泵变矩器，噪音低，动力传输平稳，换档操作简单， 只有换向操作，一进一退，搭配双高低速让您工作更加轻松。

12车桥：小轮边加重铸钢桥，国内一线品牌金驰加重型铸钢桥，加大牙包，所有的传动轴齿轮、太阳轮、行星齿轮都经过淬火处理，同时轴头部分加强了密闭性防止车桥进水，经久耐用，比同行业车桥成本要高20%。

3T Large Tire Rough Terrain Forklift (Formal Export Version)

1. Overall Dimension: 380018002300mm

2. Max Climbing Gradient: ≤38°

3. Fork Length: 1220mm

4. Rated Lifting Height: 3000mm (Customizable range: 3000–7000mm)

5. Rated Load Capacity: 3500KG

6. Ground Clearance at Mast Front: 250–350mm

7. Turning Radius: 3000mm

8. Drive Mode: 4-Wheel Drive

9. Ground Clearance at Wheelbase Center: 300mm

10. Engine Brand & Model: Quanchai 493 National Stage IV Engine, Rated Power 36.8KW. It is a well-known domestic brand featuring strong power, reliable quality and timely after-sales service.

11. Transmission: Model 280 Dual High-Low Speed Transmission equipped with large pump torque converter. Low noise and smooth power transmission with simple shifting operation. only forward & reverse switching available, paired with dual high-low speed gears to greatly ease your operation.

12. Axle: Heavy-duty cast steel axle with small wheel reducers from Jinchi, a top-tier domestic brand. Equipped with enlarged differential housing. All drive shafts, sun gears and planet gears are quenched for enhanced durability. The axle hub adopts upgraded sealing structure to avoid water ingress. Its service life is far longer, with 20% higher manufacturing cost than ordinary axles of the same industry.

13. Articulation Joint: 30mm thick national standard manganese steel plate, featuring higher strength and toughness compared with regular steel.

14. Tires: Large 23.5/70-16 engineering off-road tires, wear-resistant and puncture-proof. Solid tires or semi-solid tires are optional for different road conditions.

15. Mast: The mast C-section steel is made of national standard manganese steel with 160mm width, yield strength up to 430Mpa, high rigidity and anti-deformation. Wide-view mast design provides operators with excellent sightlines for precise handling work.

16. Radiator: Oversized radiators as standard. 4105 radiator for 3T–3.5T models, 4108 radiator for 4T–6T models, delivering superior heat dissipation to prevent overheating.

17. Brake Syst
